Thiết bị đo mức dạng sóng Radar.

Khoảng đo 0...20 mét.

-Antenna material: PTFE status

 -Process Connection Flat faced flanges (316L stainless steel): DN 50 PN 16, Type A, flat faced statusAntenna Extensions

 -Antenna Extension: No antenna extension status

 -Process Seal/Gasket: Integral Gasket, for FF flange process connections only, not for Antenna options 3,4,5,6 status

 -Enclosure/Cable inlet: Aluminum, Epoxy painted, 2 x 1/2" NPT, status

 -Communication/Output: 4-20mA HART, start-up at <3.6mA status

 -Approvals: Ordinary Locations/General Purpose (Non-Ex), CE, UKCA, RED, RCM status

 -Pressure rating: rating per pressure/temperature curves in instruction manual

Tùy chọn cơ bản -Z :

C11 : Manufacturer's Test Certificate: M to DIN 55350, Part 18 and to ISO 9000

C12 : Material Inspection certificate 3.1 of EN 10204

N07 : NAMUR: Namur NE43 compliant, device preset to failsafe <3.6mA,

Y15 : Stainless steel tag: (69 x 50 mm (2.7 x 1.97 inch)) Measuring-point number/ identification (max. 27 characters), specify in plain text
